Parade Signal Interface IC Selection and Applications

Scheme number：SMC-P1-001 Category：Interface IC

Interface circuits act as logical bridges for communication between electronic devices, peripherals, and internal components. They enable data and media exchange between processors and external systems.

SigmaStar Display Chip Solution

Scheme number：SMC-S1-002 Category：Intelligent Terminal

Video is composed of continuous image frames. Due to the persistence of vision of the human eye, when the frame sequence is played at a certain rate, what we perceive is a video with continuous motion. Given the extremely high similarity among consecutive image frames, for the convenience of storage and transmission, we need to use video codecs to encode and compress these sets of images.

Sigmastar Robotic Vacuum & Industrial Vision Solutions

Scheme number：SMC-S1-001 Category：Intelligent Terminal

Sigmastar Technology, a leading high-tech company specializing in high-performance SoC chip R&D, serves smart security, automotive, video intercom, and emerging AI markets.

Canon CMOS Image Sensors: Selection and Application

Scheme number：SMC-C1-001 Category：Sensors

Canon pioneered the adoption of CMOS sensors in mainstream cameras. In 2000, the EOS D30 digital SLR debuted Canon’s first self-developed APS-C CMOS sensor (3.25MP). By 2016, models like the 1DX Mark II, 80D, and 5D Mark IV featured integrated ADCs for enhanced dynamic range. In 2020, the EOS R5 and 2021’s EOS R3 showcased Canon’s latest stacked CMOS technology, including a 24MP full-frame sensor.

Toshiba automotive device selection and application

Scheme number：SMC-T1-001 Category：Automotive

Toshiba delivers a comprehensive portfolio of semiconductors essential for automotive electrification, focusing on automotive inverters, battery management systems (BMS), and motor drivers for applications such as electric power steering, electric water pumps, and HVAC fans. The company excels in high-voltage, low-loss power devices. Moving forward, Toshiba will continue to pioneer cutting-edge semiconductor technologies to meet tomorrow’s automotive demands.

The Richtek RT949x series 45W charging solution has further enhanced its performance!

Scheme number：SMC-RK1-002 Category：Charging Solution

Richtek has successfully rolled out the RT9490 and RT9492 battery charging chips featuring a Buck-Boost architecture, which are specifically designed to meet the demands of 45W applications. These chips are capable of efficiently managing the charging process of 2 to 4 series-connected lithium-ion/polymer batteries at a current of 5A, while also overseeing the system's power path management. By incorporating low-impedance power switches, they achieve remarkable efficiency, significantly reducing charging time and extending the battery's discharge duration.

Selection and Application of Richtek’s Analog ICs

Scheme number：SMC-RK1-001 Category：Application

Richtek focuses on the field of IC design, and its main products and services include the design, manufacture, and sales of analog ICs (power management ICs). It is also one of the top ten power management chip companies in the world. Its main products include Power Conversion ICs, Power Management ICs, Power Protection ICs, and Drivers/Plifiers ICs, providing diverse and competitive power management solutions. Richtek has become one of the world's largest suppliers of power management ICs for PC motherboards.

Richtek Automotive-grade Chip Product Selection Guide

Scheme number：SMC-RK1-003 Category：Product Selection Guide

Richtek has launched a series of innovative solutions for key automotive applications such as intelligent cockpits and Advanced Driver Assistance Systems (ADAS), creating highly integrated and safer power supply solutions for automotive system manufacturers. All our automotive products comply with the AEC-Q100 standard, meeting both current and future automotive requirements. Additionally, they have obtained IATF 16949 and ISO 26262 certifications, demonstrating our commitment to quality and safety.

Introduction to Richtek Power Management Chips and Device Selection Guide

Scheme number：SMC-RK1-004 Category：Product Selection Guide

Richtek provides comprehensive IC solutions, customized for you to address various challenges in power management design. The application scope includes desktop computer motherboards, mobile phones, digital cameras, network communication devices, backlight panels, laptops, LED lighting, and many industrial applications.

Product Series Selection of Richtek Linear Voltage Regulators (LDOs)

Scheme number：SMC-RK1-005 Category：Product Selection Guide

An LDO regulates the output voltage by controlling the conduction of the adjustment transistor in the linear region. This linear regulation method can provide a precise and noise-free output voltage and can respond quickly to changes in the load. Therefore, the main advantages of an LDO lie in its simplicity, very low usage cost and noise, as well as its fast response capability.

KIOXIA SLC Flash Selection and Application

Scheme number：SMC-K1-002 Category：Product Selection Guide

KIOXIA's SLC NAND can write a large amount of data at high speed. It is a 1-bit/cell non-volatile memory with high endurance of erase and write cycles and reliability. The Kioxia SLC NAND flash product series offers a variety of capacity and package options to meet different needs in the embedded market.

KIOXIA Storage Chip Selection and Application

Scheme number：SMC-K1-001 Category：Product Selection Guide

The NAND structure can provide extremely high cell density, achieving high storage density, and also has fast writing and erasing speeds. The cell size of NAND Flash is almost half that of NOR devices. Due to the simpler production process, the NAND structure can offer higher storage capacity within a given space, thus correspondingly reducing the price per unit of storage capacity. Nand-flash memory has advantages such as large capacity and fast rewriting speed, making it suitable for storing a large amount of data, and it has been increasingly widely used in the industry.

UTC Interface Product Series Selection and Application

Scheme number：SMC-U1-003 Category：Interface

UTC has a complete product line of analog components. Its analog ICs cover various voltage regulators, PWM control ICs, amplifiers, comparators, logic ICs, voltage translators, interface driver ICs, transistor arrays, reset ICs, and Hall effect switches. The discrete devices cover high and low voltage MOSFETs, SJMOS, diodes, BJTs, FRDs, TRIACs, SCRs, IGBTs, etc.

UTC PC Power Solution & Electronic Components Selection

Scheme number：SMC-U1-002 Category：Semiconductor

UTC has a complete product line of analog components. Its analog ICs cover various voltage regulators, PWM control ICs, amplifiers, comparators, logic ICs, voltage translators, interface driver ICs, transistor arrays, reset ICs, and Hall effect switches. The discrete devices cover high and low voltage MOSFETs, SJMOS, diodes, BJTs, FRDs, TRIACs, SCRs, IGBTs, etc.

UTC IC & Semiconductor Selection and Application

Scheme number：SMC-U1-001 Category：Semiconductor

UTC has a complete product line of analog components. Its analog ICs cover various voltage regulators, PWM control ICs, amplifiers, comparators, logic ICs, voltage translators, interface driver ICs, transistor arrays, reset ICs, and Hall effect switches. The discrete devices cover high and low voltage MOSFETs, SJMOS, diodes, BJTs, FRDs, TRIACs, SCRs, IGBTs, etc.

Sigmastar's Image Transmission Encoding/Decoding Solution

Scheme number：SMC-S1-06 Category：Intelligent Terminal

SigmaStar has core teams in chip design, algorithms, global marketing, and supply chain. It has advantages in ISP, audio and video encoding/decoding, analog circuit design, SoC system design, and self - developed IPs. The team focuses on chip R & D in fields such as security, intelligent assisted driving, the Internet of Things, and smart homes. Its products cover IP Cam, USB Cam, Car Cam, NVR, DVR, action cameras, smart homes, and smart displays.

Sigmastar Low-Light Camera Solutions

Scheme number：SMC-S1-05 Category：Intelligent Terminal

The SoC main - control chips of Sigmastar's low - light full - color camera solution are SSC377, SSC378, and SSC379. After software and hardware tuning, the SSC377/378 solutions can output “black - light - level” color images at a low illuminance of 0.0005 Lux. Among them, the SSC337 series supports 5M cameras, the SSC338 series supports 4K ultra - high - definition image resolution, and the SSC379 can support up to 16M cameras, with improved computing power and support for AI ISP functions.

Sigmastar SSC309QL: Cost-Effective AI Glasses Solution

Scheme number：SMC-S1-03 Category：Intelligent Terminal

At the Sigmastar Technology Developer Conference in 2024, Sigmastar launched the SSC309QL, a small - sized, low - power - consumption, and light - intelligent image processing chip specifically designed for the smart glasses field.

SSD210 Smart CAM display solution

Scheme number：SMC-C2-05 Category：Intelligent Terminal/Smart Home

SSD210 is a highly integrated face access and intelligent display solution with ARM Cortex-A7 main chip, dule core, 1GHz; built-in DDR2, 512Mb; integrated image sensor interface, advanced ISP; JPEG encoder support; 2D graphics engine support; TTL/Serial RGB display support and picture quality adjustable engine, Resolution up to 1280x800@60fps; SPI-Nor/Nand Flash support.

SSD222 Smart CAM Display Solution

Scheme number：SMC-C2-04 Category：Smart terminal/smart home

SSD222 is a highly integrated face access and intelligent display solution,main chip is ARM Cortex A7, dule core, 1.2GHz; built-in DDR2/,512Mb;integrated image sensor interface,advanced ISP; support JPEG baseline encoding; support 2D graphics engine; support TTL/serial RGB interface display, resolution Up to 1280x800@60fps; SPI-Nor/Nand Flash support; Ethernet ports support; Microphone input and Lineout support; QFN128 12.3x12.3mm package, chip operating temperature -20~85℃.
